| Typical
applications include dyes, herbal, pharmaceutical,
plastic, food, ceramic, agricultural products, shampoos,
tooth paste, chocolates, gelatins etc.
Features of RAJ Cone Screw
Mixers
Exceptional Mixing Accuracy
Materials are mixed successfully to an accuracy
of 1 part in 1,00,000(0.001 %) or better. With
no degradation or separation, it thoroughly blends
materials of widely differing densities and particle
shapes and sizes.
Short Mixing Time
It achieves a thoroughly homogeneous mix in 30
to 40 % the time of most conventional mixers in
the same category such depending on mixing element
speeds.
Low Power Consumption
Cone screw mixer (Nauta Mixer) require approximately
50% power over conventional blender.
Gentle Mixing Action
Fragile filaments and flakes are safe from degradation
and mixing is accomplished with minimal heat built-up
and aeration in the product.
Low Floor Space Required
Since mixer occupies less floor space, user can
free up space for other plant operations.
Full Load Starting
Its screw agitator begins axially rotating and
loosens batch material before its orbiting motion
starts. This design feature prevents stalling
and permits starting under full load in the event
of a power failure. Soft starters are available
to reduce excessive torque at start-up.
Fast, Complete Discharge
Its unique cone design provides for gravity unloading,
gives cleaner and faster batch discharge.
Easy Liquid Addition
Liquids are injected and atomized into the top
of the mixer through the hollow shaft of the drive
system.
Mixing of Partial Batches
Partial or full load batches are mixing equally
well with no reduction in mixing efficiency.
Easy to clean
The top entering drive system provides full product
protection with no bearing nor seals in direct
contact with the product. Its unique obstruction
free cone shaped design allows for quick and easy
cleaning.
Typical Applications |
